TBK-R2201

Intelligent Thermal Infrared Imager Analyzer BGA Rework Station Built-in Laser Heating De-soldering with Microscope for iPhone Circuit Board Repair

New TBK-R2201 intelligent thermal imager laser welding machine advantages:

1)Thermal imaging and high-definition diagnostic function-Automatic detection of positive and negative pole thermal imaging mainboard connection. when the power supply temperature is too high, you can notice it.

2)Precise constant temperature control on laser heating;

3)Low power consumption (55W ) but fast heating;

4)No thermal radiation, no influence on working ambient temperature;

5)Space heating solder,

6)Easy to operate for chip maintenance!

7)Aviation grade all aluminium fuselage (net weight is only 6.2 Kg)

Attention:
– Beware of hidden dangers of electricity use, and the use of the tool requires special operation qualifications.

Features:
– Thermal imaging diagnosis: rapid and accurate maintenance and replacement. Connect your motherboard to the positive and negative poles of the instrument to achieve automatic detection through thermal imaging. It can show abnormal points through its image
– Laser heating to weld and remove chips
– Adjustable thermostat system: free temperature adjustment in the range of 100-450℃, by turning the heating knob of the laser head
– Built-in high-speed computer
– Adjustable heating zones to ensure precise operation
– Self-developed product with patents
– Heating solder without heat radiation. The heating speed of the solder is fast, not affecting the non-heating area
– Designed with three holes for laser, thermal imaging and light respectively
– Its body made of aviation grade aluminum; weighs only 6.2kg/13.7lb
– 48MP 4K CCD microscope enables clearer vision of items to be repaired
– Can be connected to a HDMI display to support UHD output
– High frequency multiple zoom lens; 0.7-4.5 continuous zoom
– With a 10″ high-definition display to show details in a clearer way

Specifications:
– Brand: TBK
– Model: R-2201
– Name: Intelligent infrared laser welding machine
– Voltage: 110-220V
– Power: 100W
– Laser power: 55W
– Temperature: 100-450℃
– Light: 3W
– Heating method: Laser heating (adjustable constant temperature)
– Display: 7″
– Microscope: 4K HD CCD
– Pixels: 48MP
– Frame rate: 60 frames/s
– Power supply: DC-12V
– Magnification: 21-135 times/42-270 times
– Output method: HDMI
– External display: 10 inches
– Product Dimensions: 290 x 290 x 340mm/11.4 x 11.4 x 13.4″
– Net weight: 6.2KG/13.7LB

Package Included:
– 1 x R-2201
– 1 x Display
– 1 x Cushion
– 1 x Microscope support
– 1 x Display bracket
– 1 x Microscope
– 1 x DC + HDMI cable
– 1 x Power cord
– 1 x Instruction + Test cable
– 1 x Foot switch
– 4 x Screws
– 1 x Set of wrenches
